Description
This single-color LED dimmer is designed for easy brightness control of LED strip lights. Using the touch remote control, you can smoothly adjust light levels to create the perfect atmosphere. Each dimmer features a unique address code for interference-free operation, making it reliable for multi-device setups.
✔ Touch Remote Control – intuitive brightness adjustment
✔ Unique Address Code – prevents interference with other devices
✔ 2-Channel Output – supports higher loads with common anode connection
✔ Wide Voltage Range – works with DC 5–24V LED strips
✔ High Power Capacity – up to 192W at 12V or 384W at 24V
✔ Long-Range Remote – up to 30m wireless control via 2.4GHz
Controller Specifications
Working Temperature: -20 ~ +60℃
Supply Voltage: DC 5–24V
Output Channels: 2 channels (common anode)
Output Current: <8A per channel
Output Power: 192W (12V) / 384W (24V)
Dimensions: 120 × 62 × 24 mm
Packing Size: 185 × 145 × 52 mm
Weight: 220g
Remote Specifications
Working Temperature: -20 ~ +60℃
Power Supply: 3 × AAA batteries (1.5V each, not included)
Transmission Frequency: 2.4GHz
Standby Power Consumption: 0.015mW
Control Distance: ~30m
Weight: 94g
